PBL380
EEC electric trike for adult
The revolutionary 3 Wheel Electric Trike, a game-changer in the world of personal transportation. This EEC approved electric trike is not your average ride. It combines cutting-edge technology with sleek design to deliver an experience like no other.
With a powerful 60V 2.2KW output, this trike is a force to be reckoned with. It is equipped with a high-capacity battery, available in both Lead Acid and Lithium variants, offering a rated capacity of 80Ah or 100Ah. This ensures long-lasting power and a smooth ride every time.
But that's not all. This 3 Wheel Electric Trike also boasts an impressive top speed of 25 km/h, with the option to switch to 45 km/h for those who crave a little more excitement. Say goodbye to traffic jams and hello to freedom as you zip through the streets with ease.
relaxed life leasure time
Serial No. | Part name | Content | A380 | Remark |
1 | Vehicle parameters | Length(mm) | 2400 | |
2 | Room (mm) | 1202 | ||
3 | Height (mm) | 1625 | ||
4 | Draw distance (mm) | 1742 | ||
5 | Wheel base (mm) front/rear | -- | ||
6 | Number of seats (person) | front 1 + rear 1 | ||
7 | Body structure | Body type | monocoque body | |
8 | Body structure | 2 doors | ||
9 | power system | Motor type | Permanent magnet synchronization | |
10 | Motor rated power (kw) | 2.2 | ||
11 | Motor rated voltage (V) | 60 | ||
12 | Battery type | Lead acid/ lithium battery | ||
13 | Rated capacity (Ah) | 80Ah/100Ah | ||
14 | Range-NEDC(KM) | ＞90 / ＞100 | ||
15 | charger&charging cable | Built-in charger with gun charging plug |
| |
16 | Drive form | Drive type | Rear drive | |
17 | Basic performance | Max. speed (actual value) (km/h) | 25 or 25/45 switchable | Lowest gear speed: 25km/h |
18 | Acceleration time (0 ~30km/h) | ≤10s | ||
19 | Maximum grade% | ≥20 | ||
20 | Minimum turning diameter (mm) | ≤8500 | ||
21 | Suspension structure | Front suspension | hydraulic absorb | |
22 | Rear suspension | Trailing arm drive axle | ||
23 | wheel | Front tire | 130/60-13M/C | |
24 | Rear tire | 135/70R12 | ||
25 | Rim | aluminium alloy | ||
26 | steering system | Steering mode | Handle | |
27 | Steering gear type | Handle | ||
28 | Steering wheel material | --- | ||
29 | brake | Front/rear brake type | Front and back Disc brake | |
30 | hill-antislide assist function | yes | ||
32 | safe and comfort | Main driver's 3-point seat belt | yes | Standard configuration |
33 | 2-point seat belts for rear passengers | yes | Standard configuration | |
34 | remote key | yes | ||
35 | Window Glass lift | electric | ||
36 | one-button start | -- | ||
37 | Four-way manual adjustment of the main driver's seat | yes | ||
38 | PU seats | yes | ||
39 | Reverse camera | yes | ||
40 | Interior and exterior | Manual adjustment of exterior mirrors | yes | |
41 | Manual folding of the rear mirror | yes | ||
42 | sun roof | yes | ||
43 | Wheel decoration cover | yes | ||
44 | Built-in antenna | yes | ||
45 | Wiper spray device | yes | ||
46 | Wiper | yes | ||
47 | Cabin waterproof function | yes | ||
48 | Electrical appliances | heating system（800w） | yes | |
49 | Air conditioner (manual) | --- | Selectable | |
50 | Daytime LED driving lights | yes | ||
51 | License Plate Light | yes | ||
52 | High-position brake light | yes | ||
53 | European onboard charger | yes | ||
54 | LCD instrument | yes | ||
55 | Bluetooth device | yes | ||
56 | multimedia | LCD screen | yes | |
57 | USB charging port | yes | ||
58 | radio | with Europe DAB+ | FM: 8-108MHz; | |
59 | speaker | 2 | ||
60 | vehicle tools | User manual (including maintenance manual) | yes | |
61 | License plate holder | yes | ||
62 | Trailer hook | yes | ||
| 63 | charging plug | yes | ||
Packing,Loading&Deliver | ||||
