PBL380
High quality electric tricycle
Introducing the ultimate ride for those who dare to be different - the EEC approved, high-quality 3 wheel electric tricycle. This magnificent beast is not for the faint-hearted, but for those who crave the thrill of the open road.
This electric tricycle is equipped with a remarkable rated capacity of 80Ah/100Ah, ensuring you can conquer any journey without a worry. Designed with convenience in mind, this trike features a unique body structure with 2 doors, providing easy access for both the driver and passengers.
Not only does our electric tricycle offer practicality, but it also boasts a new and eye-catching design. At our company, we prioritize quality, and our electric tricycle is no exception. We have meticulously designed and manufactured this product using premium materials to ensure its durability and longevity. Rest assured, you are investing in a high-quality and reliable mode of transportation.
e
Serial No. | Part name | Content | A380 | Remark |
1 | Vehicle parameters | Length(mm) | 2400 | |
2 | Room (mm) | 1202 | ||
3 | Height (mm) | 1625 | ||
4 | Draw distance (mm) | 1742 | ||
5 | Wheel base (mm) front/rear | -- | ||
6 | Number of seats (person) | front 1 + rear 1 | ||
7 | Body structure | Body type | monocoque body | |
8 | Body structure | 2 doors | ||
9 | power system | Motor type | Permanent magnet synchronization | |
10 | Motor rated power (kw) | 2.2 | ||
11 | Motor rated voltage (V) | 60 | ||
12 | Battery type | Lead acid/ lithium battery | ||
13 | Rated capacity (Ah) | 80Ah/100Ah | ||
14 | Range-NEDC(KM) | ＞90 / ＞100 | ||
15 | charger&charging cable | Built-in charger with gun charging plug |
| |
16 | Drive form | Drive type | Rear drive | |
17 | Basic performance | Max. speed (actual value) (km/h) | 25 or 25/45 switchable | Lowest gear speed: 25km/h |
18 | Acceleration time (0 ~30km/h) | ≤10s | ||
19 | Maximum grade% | ≥20 | ||
20 | Minimum turning diameter (mm) | ≤8500 | ||
21 | Suspension structure | Front suspension | hydraulic absorb | |
22 | Rear suspension | Trailing arm drive axle | ||
23 | wheel | Front tire | 130/60-13M/C | |
24 | Rear tire | 135/70R12 | ||
25 | Rim | aluminium alloy | ||
26 | steering system | Steering mode | Handle | |
27 | Steering gear type | Handle | ||
28 | Steering wheel material | --- | ||
29 | brake | Front/rear brake type | Front and back Disc brake | |
30 | hill-antislide assist function | yes | ||
32 | safe and comfort | Main driver's 3-point seat belt | yes | Standard configuration |
33 | 2-point seat belts for rear passengers | yes | Standard configuration | |
34 | remote key | yes | ||
35 | Window Glass lift | electric | ||
36 | one-button start | -- | ||
37 | Four-way manual adjustment of the main driver's seat | yes | ||
38 | PU seats | yes | ||
39 | Reverse camera | yes | ||
40 | Interior and exterior | Manual adjustment of exterior mirrors | yes | |
41 | Manual folding of the rear mirror | yes | ||
42 | sun roof | yes | ||
43 | Wheel decoration cover | yes | ||
44 | Built-in antenna | yes | ||
45 | Wiper spray device | yes | ||
46 | Wiper | yes | ||
47 | Cabin waterproof function | yes | ||
48 | Electrical appliances | heating system（800w） | yes | |
49 | Air conditioner (manual) | --- | Selectable | |
50 | Daytime LED driving lights | yes | ||
51 | License Plate Light | yes | ||
52 | High-position brake light | yes | ||
53 | European onboard charger | yes | ||
54 | LCD instrument | yes | ||
55 | Bluetooth device | yes | ||
56 | multimedia | LCD screen | yes | |
57 | USB charging port | yes | ||
58 | radio | with Europe DAB+ | FM: 8-108MHz; | |
59 | speaker | 2 | ||
60 | vehicle tools | User manual (including maintenance manual) | yes | |
61 | License plate holder | yes | ||
62 | Trailer hook | yes | ||
| 63 | charging plug | yes | ||
Packing,Loading&Deliver | ||||
