PBL80-YJA
Enclosed 3 wheel electric trike
This EEC approved trike is the ultimate solution for all your commuting needs. Our new design is sure to turn heads wherever you go. With sleek lines and a modern aesthetic, this tricycle is the epitome of style and functionality.
Its maximum grade of 18 degree means it can effortlessly conquer steep inclines, making every ride an exhilarating adventure.Powered by a motor with an astonishing rated power of 2.2 kW, this trike will leave all others in its dust. With a rated voltage of 60V, it delivers electrifying performance that will leave you breathless.
We pride ourselves on delivering only the highest quality products, and this electric tricycle is no exception. Built to last, it is equipped with top-of-the-line features that guarantee a smooth and comfortable ride every time.Competitive wholesale prices are offered, with special discounts available for bulk orders,please contact us.
Model | CLOSED body with 2 doors |
Cabin material | ABS and integrated steel skeleton frame |
Size | 2380x 1195 x 1585mm |
Handling | Handle type |
Driving type | Rear wheel driving |
Wheelbase/Rear Wheeltrack | 1620mm/1000mm |
Ground clearance | 175mm |
Curb Weight | 315kg(including battery)/360kg(gross weight) |
Brake F/R | Front /Rear hydraulic disc brake |
Fort shock absorber | Hydraulic |
Tire F/R and Rim | F: 130/60-13 R: 135/70R12 aluminium alloy rim |
Motor | |
Motor Type | DC Brushless |
Output | 1500w |
Output (V) | 60V |
Rotating Speed | 3200rpm |
Controller | 36tubes |
Battery | |
Battery type | Free maintainance Lead-Acid |
Standard Battery Capacity | 60V58ah（12V*5PCS) |
Performance | |
Loading Capacity | around 200kg |
Max. Speed | 45km/25km |
Reverse Speed | 8km/h |
Driving distance | ≥ 70km per charge of one set battery |
Braking distance( 20km/h) | 3≤ m |
Minimumturn radius | 4.5m |
Climbing Ability | >18degree |
Feature&Functional device | |
electric door window/roof window/openable rear window, water spray wiper, warm air blower, FM /MP3/MP4/USB/blue tooth, reversing camera, hand brake, adjustable seat, electric speed shift, 3 points driver seat-belt, 2 points passenger seat belt,hazard warning light, three wheel disc-brake. | |
Packing,Loading&Deliver | |
Color Option
Factory/Workshop
Packing&Loading for container
new designed 1500w 2200w 3000w electric cabin scooter eec coc enclosed electric tricycle for adult popular 3 wheel electric trike scooter bike electric scooter car high quality eec coc 3 wheel 4 wheel electric cargo car for goods dispatch express food delivery advertisement hot sale electric vehicle lead acid lithium battery drive motorcycle easy to do to old people disabled handicapted 25km 45km coc electric enclosed cabin scooter open body trike scooter golf car for patrol sightseeing relaxed life
