PBL-WEI
Open body 3 wheel electric trike
We are delighted to present to you our latest offering: the popular EEC approved open body 3 wheel electric trike. This high-quality enclosed electric trike is specifically designed for adult riders who are seeking a convenient and eco-friendly mode of transportation.
With its sleek and modern design, this 3 wheel electric trike is sure to turn heads wherever you go. Its dimensions of 2375x 1210 x 1600mm ensure a comfortable and spacious ride, allowing you to enjoy your journeys to the fullest.
Model | OPEN body without door |
Cabin material | ABS and integrated steel skeleton frame |
Size | 2375x 1210 x 1600mm |
Seats | 1+2 |
Handling | Handle type |
Driving type | Rear wheel driving |
Wheelbase/Rear Wheeltrack | 1630mm/1040mm |
Ground clearance | 140mm |
Net Weight | 260kg(including battery)/285kg(gross weight) |
Brake F/R | Front /Rear hydraulic disc brake |
Parking | yes |
Fort shock absorber | Hydraulic |
Tire F/R and Rim | F: 130/60-13 R: 135/70R12 aluminium alloy rim |
Motor | |
Motor Type | sine wave, permanent magnet, DC Brushless |
Output | 1.5 kw |
Output (V) | 60V |
Transmission Ratio | 1:10 |
Controller | powerful sine wave |
Battery | |
Battery type | Free maintainance Lead-Acid |
Standard Battery Capacity | 60V58ah（12V*5PCS) |
Performance | |
Loading Capacity | 225kg |
Max. Speed | 45km |
Reverse Speed | 8km/h |
Driving distance | ≧70km per charge of one set battery |
Braking distance( 20km/h) | 3≤ m |
Minimumturn radius | 4.5m |
Climbing Ability | 20degree |
Feature | |
wiper,adjustable double arms for F/R seats, retractable 2-points safe belt, FM radio/MP3/USB high grade meter with reversing and symbol hints help for maintanence, LED light system | |
Packing,Loading&Deliver | |
Color Option
